Novastar VX600 HD LED Video Controller Video Processor for LED Display Screen

Novastar VX600 HD LED Video Controller Video Processor for LED Display Screen

Overview
Recommended Products

The Novastar VX600 Video Processor is a high-performance LED display controller built for medium to large-scale LED screen projects. It combines video processing, multi-format input, and sending card functions in one device, offering flexibility, stability, and superior image performance.

With support for HDMI 1.3, DVI, VGA, and 3G-SDI, the VX600 ensures compatibility with a wide range of video sources. It supports seamless switching, real-time image scaling, and advanced features like HDR, Genlock synchronization, and 3D LUT color calibration—ideal for live events, studios, exhibitions, and commercial installations.

The VX600 delivers a total loading capacity of up to 3.9 million pixels, and supports up to 6 layers including one background and five overlay layers. It also includes 4 Gigabit Ethernet outputs and 1 optical fiber port, making it suitable for high-resolution LED setups requiring stable, high-bandwidth performance.

Engineered for reliability and controlled through NovaLCT or SmartLCT, the VX600 video processor works seamlessly with Novastar receiving cards like MRV336, MRV328, and A8s. Whether you're managing a stage setup or a fixed display project, the VX600 delivers industry-level quality and control.

Novastar VX600 HD LED Video Controller Video Processor for LED Display Screen supplier

Specification

Power interface	100-240V~，1.6A，50/60Hz
Rated power consumption	28W
Operating temperature	-10℃ ~ +45℃
Working humidity	20%RH ~ 90%RH
Storage temperature	-20℃ ~ +70℃
Storage humidity	10%RH ~ 95%RH
Package Size	565175450mm
Gross weight	6.8Kg

Products Description

VX600 is a 6-port two-in-one video controller that integrates video processing and control functions. Supports three device working modes: video control mode, photoelectric conversion mode and ByPass mode. A single device can carry a maximum of 3.9 million pixels, with a maximum width of 10,240 pixels and a maximum of 8,192 pixels, meeting the needs of on-site ultra-wide and ultra-high display control. VX600 can receive and process a variety of video signals, has high-definition image processing capabilities, and supports functions such as stepless scaling of output images, low latency, and point-by-point chroma correction, providing excellent image display. VX600 also supports LED display configuration and device network port identification through NovaLCT, and layer management, scene management and firmware upgrade operations through V-Can, simplifying device control. With its powerful video processing and sending capabilities, VX600 is widely used in mid-to-high-end rental, stage control and engineering small-pitch LED display fields.
