solutio Clavis ad Usum pro Ostentu LED Interiore P4 Multicolor 500x1000mm cum Coniunctione Sine Intermissione et Muro Videorum
- Conspectus
- Producta commendata
Parametros Producti
Spatium pixelorum |
2.604 mm |
2.976 mm |
3.91 mm |
4.81 mm |
|||
Pixels per cabinet |
192 × 192 (H × V) |
168 × 168 (H × V) |
128 × 128 (H × V) |
104×104 (H×V) |
|||
Duratio lucis LED |
100 000 h (video – 50% claritas) |
||||||
Splendor |
≥1000 nits |
||||||
Magnitudo moduli |
250×250 mm |
||||||
Resolutio Moduli |
96×96 puncta |
84×84 puncta |
64×64 puncta |
52*52 puncta |
|||
Frequentia Renovationis |
960-1.920 Hz |
||||||
Angulus visus horizontalis |
140° ±5° (@50% claritas) |
||||||
Angulus visus verticalis |
140° ±5° (@50% claritas) |
||||||
Uniformitas claritatis |
98% |
||||||
Attenutio |
0-100% |
||||||
Nivelus cinereus |
14 bita |
||||||
Potentia media consumpta |
350 W/m² |
320 W/m² |
300 W/m² |
280 W/m² |
|||
Potentia maxima consumpta |
680 W/m² |
640 W/m² |
620 W/m² |
600 W/m² |
|||
Operation power voltage |
100-240V / 50-60Hz |
||||||
Operational temperature |
-10°C to +40°C / 14°F to 104°F |
||||||
Classificatio IP |
IP54 for Indoor, IP65 for Outdoor |
||||||
Serviceability |
Front and back service |
||||||
Descriptio Productorum
Genera productorum
Mensura armarium: 960*960*86mm
Maxima crassitudo mensurae: 960*960*110mm
Mensura modulus: 320*160mm
pondus: 13kg
Modulus: P2.5/P4/P5/P6.67/P8/P10
Material: congeries magnesii
installatio: suspensio et installatio fixa
Usus: interior IP30; exterior IP65
Magnitudo: 640*480*54mm
Pondus: 3.25kg
Mensura modulus: 320*160mm
Modulus:P1.6/P1.8/P2.5/P4/P5
Material: congeries magnesii
installatio: suspensio & installatio fixa
Usus: intramuralis
Mensis magnitudo: 500*500*73mm/500*1000*73mm
Pondus mensis: 3.7kg/5.5kg
Modulus magnitudo: 250*250mm
Modulus: P2.604/P2.976/P3.91/P4.81
Materies: Magnesii Confoederatio
installatio: suspensio & installatio fixa
Impermeabilitas: exterior lP65 & interior IP30
Dimensiones (mm): 1000*500*80mm/ 1000*1000*80mm
Modus connexionis parvae: Seratio celer
Materialis: Aluminiuum funditum
Conservatio: Conservatio a fronte / Conservatio ab retro Protectio
classis:IP65
pondus (metrum quadratum): 15 kg
Grayscale: 14 bitium
