LED Display
murus Imaginum LED 4m X 3m 500x500mm, Provisor Ostentus LED pro Publicitate Altae Resolutionis
- Conspectus
- Producta commendata
Parametros Producti
Spatium pixelorum |
2.604 mm |
2.976 mm |
3.91 mm |
4.81 mm |
|||
Pixels per cabinet |
192 × 192 (H × V) |
168 × 168 (H × V) |
128 × 128 (H × V) |
104×104 (H×V) |
|||
Duratio lucis LED |
100 000 h (video – 50% claritas) |
||||||
Splendor |
≥1000 nits |
||||||
Magnitudo moduli |
250×250 mm |
||||||
Resolutio Moduli |
96×96 puncta |
84×84 puncta |
64×64 puncta |
52*52 puncta |
|||
Frequentia Renovationis |
960-1.920 Hz |
||||||
Angulus visus horizontalis |
140° ±5° (@50% claritas) |
||||||
Angulus visus verticalis |
140° ±5° (@50% claritas) |
||||||
Uniformitas claritatis |
98% |
||||||
Attenutio |
0-100% |
||||||
Nivelus cinereus |
14 bita |
||||||
Potentia media consumpta |
350 W/m² |
320 W/m² |
300 W/m² |
280 W/m² |
|||
Potentia maxima consumpta |
680 W/m² |
640 W/m² |
620 W/m² |
600 W/m² |
|||
Operation power voltage |
100-240V / 50-60Hz |
||||||
Operational temperature |
-10°C to +40°C / 14°F to 104°F |
||||||
Classificatio IP |
IP54 for Indoor, IP65 for Outdoor |
||||||
Serviceability |
Front and back service |
||||||
Descriptio Productorum
Applicatio
Locatio externa
Particularia cabinetis
Modulus
Descriptio Producti
Descriptio Producti
Solutio
PARTES SUPPLEMENTARIAE
sERIES 500x1000mm
INTERIOR CUMULI
Methodus manutentionis
Installatio
Descriptio Societatis
Officina
